Please contact us for more photos of EEVTG1H221Q
| Part Number | EEVTG1H221Q |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 568760 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Aluminum 220uF 50V 20% (12.5 X 13.5mm) SMD 0.23 Ohm 600mA 2000h 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Aluminum |
| ROHS Compliant | Yes |
| MSL Level | EEVTG1H221Q |
| Datasheet download |  EEVTG1H221Q.pdf |
| Part Number | EEVTG1H221Q |
|---|---|
| Mounting | Surface Mount |
| Capacitance Value | 220 uF |
| Construction | Cylindrical |
| Equivalent Series Resistance | 0.23 Ohm |
| Lead Finish | Tin |
| Leakage Current | 110@2Min uA |
| Rad Hard | No |
| Operating Temperature | -40 to 125 °C |
| Tolerance | 20 % |
| Product Dimensions | 13.5 mm |
| Ripple Current | 600 mA |
| Max Processing Temp | 230 |
| Voltage(DC) | 50 V |
| Package/Case | 12.5 X 13.5 |
| Product Diameter | 12.5 mm |
| Product Height | 13.5 mm |
| Replacement Part Number | PART-EEVTG1H221Q |
| Weight | Contact us |
| Country of Origin | - |
