Please contact us for more photos of EVM2GSX80B16
| Part Number | EVM2GSX80B16 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 301700 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Cermet Trimmer 1M Ohm 20% 3 20W 1(Elec) 1(Mech)Turns (2.2 x 2.81 x 0.85mm) Foot Print SMD T R |
| Category | Resistor |
| Family | Resistor Trimmers, Potentiometers and Rheostats |
| ROHS Compliant | Yes |
| MSL Level | EVM2GSX80B16 |
| Datasheet download |  EVM2GSX80B16.pdf |
| Part Number | EVM2GSX80B16 |
|---|---|
| Product Dimensions | 2.2 x 2.81 x 0.85 |
| Power Rating | 0.15 W |
| Temperature Coefficient | ±250 ppm |
| Termination Style | Foot Print |
| Rad Hard | No |
| Pin Count | 2 |
| Max Processing Temp | 260 |
| Tolerance | 20 % |
| Resistance Value | 1 MOhm |
| Mounting | Surface Mount |
| Technology | Cermet |
| Operating Temperature | -40 to 100 °C |
| Lead Finish | Tin|Palladium |
| Product Depth | 2.81 mm |
| Product Height | 0.85 mm |
| Product Length | 2.2 mm |
| Replacement Part Number | PART-EVM2GSX80B16 |
| Weight | Contact us |
| Country of Origin | - |
