Please contact us for more photos of EVM2NSX80BC3
| Part Number | EVM2NSX80BC3 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 510030 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Cermet Trimmer 1.5K Ohm 0.25% 3 20W 1Turns (2.2 x 2.81 x 0.81mm) Foot Print SMD T R |
| Category | Resistor |
| Family | Resistor Trimmers, Potentiometers and Rheostats |
| ROHS Compliant | Yes |
| MSL Level | EVM2NSX80BC3 |
| Datasheet download |  EVM2NSX80BC3.pdf |
| Part Number | EVM2NSX80BC3 |
|---|---|
| Type | Trimmer |
| Operating Temperature | -40 to 100 °C |
| Tolerance | ±25 % |
| Number of Turns | 1 Turns |
| Resistance Value | 1.5 kOhm |
| Package Type | Surface Mount/Foot Print |
| Package Dimensions | 2.2 x 2.81 x 0.81 mm |
| Rad Hard | No |
| Power Rating | 3/20 W |
| Mounting | Surface Mount |
| Maximum Processing Temperature | 260 °C |
| Technology | Cermet |
| Temperature Coefficient | ±250 ppm/°C |
| Pin Count | 3 |
| Termination Style | Foot Print |
| Product Depth | 2.81 mm |
| Product Height | 0.81 mm |
| Product Length | 2.2 mm |
| Replacement Part Number | PART-EVM2NSX80BC3 |
| Weight | Contact us |
| Country of Origin | - |
