Please contact us for more photos of EVMAASA00B52
| Part Number | EVMAASA00B52 |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 780040 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Cermet Trimmer 500 Ohm 25% 3 10W 1Turn 3.6mm (7.8 X 6.9 X 7.6mm) Pin Thru-Hole Ammo Pack |
| Category | Resistor |
| Family | Resistor Trimmers, Potentiometers and Rheostats |
| ROHS Compliant | Yes |
| MSL Level | EVMAASA00B52 |
| Datasheet download |  EVMAASA00B52.pdf |
| Part Number | EVMAASA00B52 |
|---|---|
| Product Dimensions | 7.8 x 6.9 x 7.6 mm |
| Temperature Coefficient | ±200 ppm |
| Number of Turns | 1 Turns |
| Power Rating | 0.3 W |
| Technology | Cermet |
| Termination Style | Pin |
| Lead Finish | Tin |
| Max Processing Temp | 250 to 260 |
| Mounting | Through Hole |
| Shaft Diameter | 3.6 mm |
| Resistance Value | 500 Ohm |
| Tolerance | 25 % |
| Type | Trimmer |
| Rad Hard | No |
| Package Type | Through Hole/Pin |
| Product Depth | 6.9 mm |
| Product Height | 7.6 mm |
| Product Length | 7.8 mm |
| Replacement Part Number | PART-EVMAASA00B52 |
| Weight | Contact us |
| Country of Origin | - |
