Please contact us for more photos of EXB28V101J
| Part Number | EXB28V101J |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 409700 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film Array 100 Ohm 5% \u00b1200ppm \u00b0C ISOL Molded 8-Pin 0804 Convex SMD Embossed Carrier T R |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | EXB28V101J |
| Datasheet download |  EXB28V101J.pdf |
| Part Number | EXB28V101J |
|---|---|
| Type | Array |
| Technology | Thick Film |
| Case Size per Element | 0402 |
| Circuit Designator | ISOL |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| Pin Count | 8 |
| Operating Temperature | -55 to 125 °C |
| Number of Terminals | 8 |
| Supplier Package | 0804 |
| Case Size | 0804 |
| Termination Style | Convex |
| Number of Resistors | 4 |
| Temperature Coefficient | ±200 ppm/°C |
| Case Style | Molded |
| Package Dimensions | 2 x 1 x 0.35 mm |
| Maximum Processing Temperature | 260 °C |
| Resistance Value | 100 Ohm |
| Terminal Pitch | 0.5 mm |
| Tolerance | 5 % |
| Rad Hard | No |
| Product Depth | 1 mm |
| Product Height | 0.35 mm |
| Product Length | 2 mm |
| Product Weight | 2 mg |
| Replacement Part Number | PART-EXB28V101J |
| Weight | Contact us |
| Country of Origin | - |
