Please contact us for more photos of EXBU24390JX
| Part Number | EXBU24390JX |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 891630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film Array 39 Ohm 5% \u00b1200ppm \u00b0C ISOL Molded 4-Pin 0404 Convex SMD Punched Paper T R |
| Category | Resistor |
| Family | Resistor Networks and Arrays |
| ROHS Compliant | Yes |
| MSL Level | EXBU24390JX |
| Datasheet download |  EXBU24390JX.pdf |
| Part Number | EXBU24390JX |
|---|---|
| Termination Style | Convex |
| Military Standard | |
| Failure Rate | |
| Number of Resistors | |
| Package Type | |
| Number of Terminals | |
| Circuit Designator | ISOL |
| Rad Hard | No |
| Supplier Package | 0404 |
| Power Rating per Resistor | 1/16 W |
| Temperature Coefficient | ±200 ppm/°C |
| Tolerance | 5 % |
| Case Style | Molded |
| Max Processing Temp | 260 |
| Technology | Thick Film |
| Mounting | Surface Mount |
| Case Size | 0404 |
| Resistance Value | 39 Ohm |
| Product Dimensions | 1 x 1 x 0.35 |
| Pin Count | 4 |
| Lead Finish | Tin |
| Case Size per Element | 0402 |
| Type | Array |
| Termination Material | Silver|Palladium |
| Operating Temperature | -55 to 125 °C |
| Terminal Pitch | 0.65 mm |
| Product Depth | 1 mm |
| Product Height | 0.35 mm |
| Product Length | 1 mm |
| Product Weight | 1.2 mg |
| Replacement Part Number | PART-EXBU24390JX |
| Weight | Contact us |
| Country of Origin | - |
