Please contact us for more photos of JX80-0019NL
| Part Number | JX80-0019NL |
|---|---|
| Manufacturer | Pulse |
| Quantity in stock | 855570 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn RJ-45 Integrated Magnetics RCP 16 POS Solder RA Thru-Hole 24 Terminal 2 Port Tray |
| Category | Connectors |
| Family | Connector Telephone and Telecom |
| ROHS Compliant | Yes |
| MSL Level | JX80-0019NL |
| Datasheet download |  JX80-0019NL.pdf |
| Part Number | JX80-0019NL |
|---|---|
| Contact Plating | Gold Over Nickel |
| Max Processing Temp | 260 |
| Lead Finish | Gold Over Nickel |
| Rad Hard | No |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Number of Terminals | 24 |
| Pin Count | 24 |
| Termination Method | Solder |
| Number of Contacts | 16 |
| Type | RJ-45 Integrated Magnetics |
| Product Dimensions | 31.18 x 21.36 x 13.61 |
| MSL Level | 1 |
| Number of Ports | 2 |
| Gender | RCP |
| Body Orientation | Right Angle |
| Mounting | Through Hole |
| Operating Temperature | -45 to 85 °C |
| Product Depth | 21.36 mm |
| Product Height | 13.61 mm |
| Product Length | 31.18 mm |
| Replacement Part Number | PART-JX80-0019NL |
| Weight | Contact us |
| Country of Origin | - |
