Please contact us for more photos of BAV23C-7-F
| Part Number | BAV23C-7-F |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 790620 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 250V 0.4A 3-Pin SOT-23 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAV23C-7-F |
| Datasheet download |  BAV23C-7-F.pdf |
| Part Number | BAV23C-7-F |
|---|---|
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Peak Reverse Repetitive Voltage | 250 V |
| Peak Non-Repetitive Surge Current | 9 A |
| Screening Level | Commercial |
| Supplier Package | SOT-23 |
| Peak Reverse Current | 0.1@200V uA |
| MSL Level | 1 |
| Pin Count | 3 |
| Configuration | Dual Common Cathode |
| Type | Switching Diode |
| Max Processing Temp | 260 |
| Product Dimensions | 2.9 x 1.3 x 1 mm |
| Peak Average Forward Current | 0.4 A |
| Rad Hard | No |
| Peak Forward Voltage | [email protected] V |
| Peak Reverse Recovery Time | 50 ns |
| Operating Temperature | -65 to 150 °C |
| Package | 3SOT-23 |
| Replacement Part Number | PART-BAV23C-7-F |
| Weight | Contact us |
| Country of Origin | - |
