Please contact us for more photos of BAV99-HE3-08
| Part Number | BAV99-HE3-08 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 132280 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Small Signal Switching 70V 0.15A 3-Pin SOT-23 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | BAV99-HE3-08 |
| Datasheet download |  BAV99-HE3-08.pdf |
| Part Number | BAV99-HE3-08 |
|---|---|
| Pin Count | 3 |
| Peak Average Forward Current | 0.15 A |
| Rad Hard | No |
| Peak Reverse Recovery Time | 6 ns |
| Lead Finish | Tin |
| Product Dimensions | 3.1(Max) x 1.43(Max) x 1.05(Max) |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Peak Reverse Repetitive Voltage | 70 V |
| Configuration | Dual Series |
| Type | Small Signal Switching Diode |
| Peak Forward Voltage | 1.25@150mA V |
| Peak Non-Repetitive Surge Current | 4.5 A |
| Peak Reverse Current | 2.5@70V uA |
| Supplier Package | SOT-23 |
| Operating Temperature | -55 to 150 °C |
| Package | 3SOT-23 |
| Replacement Part Number | PART-BAV99-HE3-08 |
| Weight | Contact us |
| Country of Origin | - |
