Please contact us for more photos of CUS05S30,H3F
| Part Number | CUS05S30,H3F |
|---|---|
| Manufacturer | Toshiba |
| Quantity in stock | 325200 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 2-Pin SOD-323 |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | CUS05S30,H3F |
| Datasheet download |  CUS05S30,H3F.pdf |
| Part Number | CUS05S30,H3F |
|---|---|
| Screening Level | Military |
| Pin Count | 2 |
| Operating Temperature | -55 to 125 |
| Peak Reverse Current | 300 uA |
| Peak Forward Voltage | 0.34 V |
| Peak Non-Repetitive Surge Current | 5 A |
| Configuration | Single |
| Type | Schottky Diode |
| Supplier Package | SOD-323 |
| Product Dimensions | 1.7 x 1.25 x 0.9 |
| Lead Finish | Tin|Silver |
| Rad Hard | No |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Package | 2SOD-323 |
| Replacement Part Number | PART-CUS05S30,H3F |
| Weight | Contact us |
| Country of Origin | - |
