Please contact us for more photos of DA2JF8100L
| Part Number | DA2JF8100L |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 351960 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 800V 0.2A 2-Pin SMini2-F5-B T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | DA2JF8100L |
| Datasheet download |  DA2JF8100L.pdf |
| Part Number | DA2JF8100L |
|---|---|
| Mounting | Surface Mount |
| Peak Reverse Repetitive Voltage | 800 V |
| Type | Switching Diode |
| Product Dimensions | 1.7 x 1.25 x 0.7 |
| Screening Level | Industrial |
| MSL Level | 1 |
| Peak Non-Repetitive Surge Current | 1 A |
| Lead Finish | Tin|Bismuth |
| Peak Forward Voltage | 2.5 V |
| Peak Reverse Current | 10 uA |
| Peak Reverse Recovery Time | 45 ns |
| Peak Average Forward Current | 0.2 A |
| Configuration | Single |
| Operating Temperature | -40 to 85 °C |
| Pin Count | 2 |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Supplier Package | SMini2-F5-B |
| Package | 2SMini2-F5-B |
| Replacement Part Number | PART-DA2JF8100L |
| Weight | Contact us |
| Country of Origin | - |
