Please contact us for more photos of DB2J20100L
| Part Number | DB2J20100L |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 377700 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 20V 0.5A 2-Pin SC-90A Embossed T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | DB2J20100L |
| Datasheet download |  DB2J20100L.pdf |
| Part Number | DB2J20100L |
|---|---|
| Peak Reverse Current | 10@10V uA |
| Pin Count | 2 |
| Peak Reverse Repetitive Voltage | 20 V |
| Rad Hard | No |
| Peak Average Forward Current | 0.5 A |
| Operating Temperature | -40 to 85 °C |
| Configuration | Single |
| Supplier Package | SC-90A |
| Peak Forward Voltage | [email protected] V |
| Peak Reverse Recovery Time | 4.3 ns |
| Mounting | Surface Mount |
| Product Dimensions | 1.7 x 1.25 x 0.7 |
| Type | Switching Diode |
| Peak Non-Repetitive Surge Current | 3 A |
| MSL Level | 1 |
| Lead Finish | Tin|Bismuth |
| Screening Level | Industrial |
| Package | 2SC-90A |
| Replacement Part Number | PART-DB2J20100L |
| Weight | Contact us |
| Country of Origin | - |
