Please contact us for more photos of DD261N20K
| Part Number | DD261N20K |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 403810 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Rectifier Diode Module (non Schottky) 2000V 260A 3-Pin PB50-1 Tray |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | DD261N20K |
| Datasheet download |  DD261N20K.pdf |
| Part Number | DD261N20K |
|---|---|
| Mounting | Screw |
| Product Dimensions | 115 x 50 x 52 |
| Peak Forward Voltage | 1.42@800A V |
| Peak Reverse Current | 40000 uA |
| Operating Temperature | -40 to 150 °C |
| Peak Reverse Repetitive Voltage | 2000 V |
| Peak Average Forward Current | 260@Tc=100C A |
| Configuration | Dual Series |
| Supplier Package | PB50-1 |
| Rad Hard | No |
| MSL Level | 1 |
| Peak Non-Repetitive Surge Current | 9500 A |
| Type | Rectifier Diode |
| Pin Count | 3 |
| Package | 3PB50-1 |
| Replacement Part Number | PART-DD261N20K |
| Weight | Contact us |
| Country of Origin | - |
