Please contact us for more photos of FR101G
| Part Number | FR101G |
|---|---|
| Manufacturer | Leshan Radio |
| Quantity in stock | 812520 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky Fast Recovery Rectifier 50V 1A 2-Pin DO-41 |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | FR101G |
| Datasheet download |  FR101G.pdf |
| Part Number | FR101G |
|---|---|
| Pin Count | 2 |
| Mounting | Through Hole |
| Rad Hard | No |
| Operating Temperature | -50 to 150 °C |
| Peak Non-Repetitive Surge Current | 30 A |
| Configuration | Single |
| Peak Reverse Current | 100 uA |
| Max Processing Temp | 260 |
| Product Dimensions | 2.7(Max) x 5.2(Max) |
| Supplier Package | DO-41 |
| Type | Fast Recovery Rectifier |
| Peak Reverse Recovery Time | 150 ns |
| Peak Reverse Repetitive Voltage | 50 V |
| Peak Average Forward Current | 1 A |
| Peak Forward Voltage | 1.3@1A V |
| Package | 2DO-41 |
| Replacement Part Number | PART-FR101G |
| Weight | Contact us |
| Country of Origin | - |
