Please contact us for more photos of LBAT54CWT1G
| Part Number | LBAT54CWT1G |
|---|---|
| Manufacturer | Leshan Radio |
| Quantity in stock | 517410 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky Barrier 0.2A 3-Pin SC-70 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | LBAT54CWT1G |
| Datasheet download |  LBAT54CWT1G.pdf |
| Part Number | LBAT54CWT1G |
|---|---|
| Peak Reverse Recovery Time | 5 ns |
| Peak Forward Voltage | [email protected] V |
| Mounting | Surface Mount |
| Configuration | Dual Common Cathode |
| Peak Reverse Current | 2@25V uA |
| Pin Count | 3 |
| Package Dimensions | 2.2 x 1.35 x 0.9 mm |
| Screening Level | Military |
| Type | Schottky Barrier Diode |
| Rad Hard | No |
| Operating Temperature | -55 to 150 °C |
| Supplier Package | SC-70 |
| Peak Non-Repetitive Surge Current | 0.6 A |
| Peak Average Forward Current | 0.2 A |
| Package | 3SC-70 |
| Replacement Part Number | PART-LBAT54CWT1G |
| Weight | Contact us |
| Country of Origin | - |
