MBRF10H150CTG ON Semiconductor

MBRF10H150CTG Images

Please contact us for more photos of MBRF10H150CTG

Part Number MBRF10H150CTG
Manufacturer ON Semiconductor
Quantity in stock 628560 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 100V 10A 3-Pin(3+Tab) TO-220 Full-Pak Rail
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level MBRF10H150CTG
Datasheet download MBRF10H150CTG.pdf
Request Quotation for MBRF10H150CTG

MBRF10H150CTG Specifications

Part Number MBRF10H150CTG
Rad Hard No
Peak Average Forward Current 10 A
Type Schottky Diode
Max Processing Temp 260
Product Dimensions 10.63 x 4.9 x 9.24 mm
Operating Temperature -20 to 150 °C
Mounting Through Hole
Peak Reverse Repetitive Voltage 100 V
Supplier Package TO-220 Full-Pak
Peak Forward Voltage 0.85@5A V
Pin Count 3
Peak Reverse Current 45 uA
Configuration Dual Common Cathode
Lead Finish Matte Tin
Peak Non-Repetitive Surge Current 150 A
Package 3TO-220 Full-Pak
Replacement Part Number PART-MBRF10H150CTG
Weight Contact us
Country of Origin -
