Please contact us for more photos of MBRS2040LT3G
| Part Number | MBRS2040LT3G |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 873460 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 40V 2A 2-Pin SMB T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MBRS2040LT3G |
| Datasheet download |  MBRS2040LT3G.pdf |
| Part Number | MBRS2040LT3G |
|---|---|
| Product Dimensions | 4.32 x 3.56 x 2.2 mm |
| MSL Level | 1 |
| Type | Schottky Diode |
| Pin Count | 2 |
| Operating Temperature | -55 to 125 °C |
| Peak Reverse Current | 800 uA |
| Peak Non-Repetitive Surge Current | 70 A |
| Supplier Package | SMB |
| Peak Average Forward Current | 2 A |
| Configuration | Single |
| Peak Forward Voltage | 0.5@4A V |
| Peak Reverse Repetitive Voltage | 40 V |
| Mounting | Surface Mount |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Lead Finish | Matte Tin |
| Package | 2SMB |
| Replacement Part Number | PART-MBRS2040LT3G |
| Weight | Contact us |
| Country of Origin | - |
