Please contact us for more photos of MCL4148-TR3
| Part Number | MCL4148-TR3 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 738080 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Small Signal Switching 100V 0.2A 2-Pin MicroMELF T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MCL4148-TR3 |
| Datasheet download |  MCL4148-TR3.pdf |
| Part Number | MCL4148-TR3 |
|---|---|
| Type | Small Signal Switching Diode |
| Mounting | Surface Mount |
| Max Processing Temp | 235 to 260|260 |
| Peak Reverse Recovery Time | 8 ns |
| Peak Reverse Repetitive Voltage | 100 V |
| MSL Level | 1 |
| Peak Reverse Current | 5@75V uA |
| Product Dimensions | 2 x 1.2 x 1.2 mm |
| Supplier Package | MicroMELF |
| Operating Temperature | -65 to 175 °C |
| Pin Count | 2 |
| Rad Hard | No |
| Peak Average Forward Current | 0.2 A |
| Peak Non-Repetitive Surge Current | 2 A |
| Configuration | Single |
| Peak Forward Voltage | [email protected] V |
| Lead Finish | Tin/Silver |
| Package | 2MicroMELF |
| Replacement Part Number | PART-MCL4148-TR3 |
| Weight | Contact us |
| Country of Origin | - |
