MMBD4448HT-7-F Diodes Incorporated

Please contact us for more photos of MMBD4448HT-7-F

Part Number	MMBD4448HT-7-F
Manufacturer	Diodes Incorporated
Quantity in stock	128590 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Diode Switching 80V 0.25A 3-Pin SOT-523 T R
Category	Discrete Semiconductor
Family	Diode
ROHS Compliant	Yes
MSL Level	MMBD4448HT-7-F
Datasheet download	MMBD4448HT-7-F.pdf

Request Quotation for MMBD4448HT-7-F

MMBD4448HT-7-F Specifications

Part Number	MMBD4448HT-7-F
Rad Hard	No
Max Processing Temp	260
Configuration	Single
Peak Reverse Repetitive Voltage	80 V
Product Dimensions	1.6 x 0.8 x 0.75 mm
Supplier Package	SOT-523
Operating Temperature	-65 to 150 °C
Peak Reverse Recovery Time	4 ns
Lead Finish	Matte Tin
Peak Average Forward Current	0.25 A
Peak Non-Repetitive Surge Current	4 A
Pin Count	3
Mounting	Surface Mount
Peak Reverse Current	0.1@70V uA
Type	Switching Diode
MSL Level	1
Peak Forward Voltage	[email protected] V
Package	3SOT-523
Replacement Part Number	PART-MMBD4448HT-7-F
Weight	Contact us
Country of Origin	-
