Please contact us for more photos of MMBD4448HTW-7-F
| Part Number | MMBD4448HTW-7-F |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 632990 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 80V 0.5A 6-Pin SOT-363 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MMBD4448HTW-7-F |
| Datasheet download |  MMBD4448HTW-7-F.pdf |
| Part Number | MMBD4448HTW-7-F |
|---|---|
| Configuration | Triple Parallel |
| Screening Level | Commercial |
| Operating Temperature | -65 to 150 °C |
| Supplier Package | SOT-363 |
| Max Processing Temp | 260 |
| Peak Non-Repetitive Surge Current | 4 A |
| Peak Forward Voltage | [email protected] V |
| Product Dimensions | 2.2 x 1.35 x 1 mm |
| Peak Reverse Repetitive Voltage | 80 V |
| Peak Reverse Recovery Time | 4 ns |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Mounting | Surface Mount |
| Type | Switching Diode |
| Pin Count | 6 |
| Peak Average Forward Current | 0.5 A |
| Peak Reverse Current | 0.1@70V uA |
| MSL Level | 1 |
| Package | 6SOT-363 |
| Replacement Part Number | PART-MMBD4448HTW-7-F |
| Weight | Contact us |
| Country of Origin | - |
