Please contact us for more photos of PMEG4020ER,115
| Part Number | PMEG4020ER,115 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 137140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 40V 2A 2-Pin SOD-123W T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | PMEG4020ER,115 |
| Datasheet download |  PMEG4020ER,115.pdf |
| Part Number | PMEG4020ER,115 |
|---|---|
| Rad Hard | No |
| Peak Non-Repetitive Surge Current | 50 A |
| Peak Forward Voltage | 0.49 V |
| Mounting | Surface Mount |
| Lead Finish | Tin |
| MSL Level | 1 |
| Operating Temperature | -65 to 150 °C |
| Supplier Package | SOD-123W |
| Peak Reverse Current | 100 uA |
| Peak Reverse Repetitive Voltage | 40 V |
| Pin Count | 2 |
| Max Processing Temp | 260 |
| Peak Average Forward Current | 2 A |
| Product Dimensions | 2.8 x 1.9 mm |
| Type | Schottky Diode |
| Configuration | Single |
| Package | 2SOD-123W |
| Replacement Part Number | PART-PMEG4020ER,115 |
| Weight | Contact us |
| Country of Origin | - |
