Please contact us for more photos of PMEG6010ER S500X
| Part Number | PMEG6010ER S500X |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 238140 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky Barrier Rectifier 60V 1A 2-Pin SOD-123 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | PMEG6010ER S500X |
| Datasheet download |  PMEG6010ER S500X.pdf |
| Part Number | PMEG6010ER S500X |
|---|---|
| Rad Hard | No |
| Mounting | Surface Mount |
| Peak Average Forward Current | 1@Ta=110C A |
| Operating Temperature | -55 to 150 °C |
| Lead Finish | Tin |
| Supplier Package | SOD-123 |
| Moisture Sensitivity Level | 1 |
| Peak Forward Voltage | 0.53@1A V |
| Type | Schottky Barrier Diode |
| Package Dimensions | 2.8 x 1.9 x 1.1 mm |
| Configuration | Single |
| Peak Reverse Current | 60@60V uA |
| Maximum Processing Temperature | 260 °C |
| Peak Reverse Repetitive Voltage | 60 V |
| Pin Count | 2 |
| Package | 2SOD-123 |
| Replacement Part Number | PART-PMEG6010ER S500X |
| Weight | Contact us |
| Country of Origin | - |
