Please contact us for more photos of RB520CM-30T2R
| Part Number | RB520CM-30T2R |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 888330 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky Diode 30V 0.1A 2-Pin VMN T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | RB520CM-30T2R |
| Datasheet download |  RB520CM-30T2R.pdf |
| Part Number | RB520CM-30T2R |
|---|---|
| Peak Average Forward Current | 0.1 A |
| Peak Forward Voltage | [email protected] V |
| Peak Reverse Repetitive Voltage | 30 V |
| Peak Non-Repetitive Surge Current | 0.5 A |
| Pin Count | 2 |
| Package Dimensions | 0.86 x 0.6 x 0.27 mm |
| Maximum Processing Temperature | 260 °C |
| Configuration | Single |
| Type | Schottky Diode |
| Rad Hard | No |
| Mounting | Surface Mount |
| Operating Temperature | -40 to 150 °C |
| Peak Reverse Current | 0.5@10V uA |
| Lead Finish | Tin |
| Supplier Package | VMN |
| Package | 2VMN |
| Replacement Part Number | PART-RB520CM-30T2R |
| Weight | Contact us |
| Country of Origin | - |
