Please contact us for more photos of S1B
| Part Number | S1B |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 272630 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 100V 1A 2-Pin DO-214AC T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | S1B |
| Datasheet download |  S1B.pdf |
| Part Number | S1B |
|---|---|
| Product Dimensions | 4.75 x 2.95 x 2.2 mm |
| Configuration | Single |
| Pin Count | 2 |
| Mounting | Surface Mount |
| MSL Level | 1 |
| Operating Temperature | -55 to 150 °C |
| Peak Average Forward Current | 1@Ta=100C A |
| Peak Non-Repetitive Surge Current | 30 A |
| Peak Reverse Current | 1 uA |
| Max Processing Temp | 260 |
| Supplier Package | DO-214AC |
| Rad Hard | No |
| Type | Switching Diode |
| Peak Reverse Repetitive Voltage | 100 V |
| Peak Reverse Recovery Time | 1800 ns |
| Peak Forward Voltage | 1.1 V |
| Lead Finish | Matte Tin |
| Package | 2DO-214AC |
| Replacement Part Number | PART-S1B |
| Weight | Contact us |
| Country of Origin | - |
