S5M-E3 9AT Vishay

S5M-E3 9AT Images

Please contact us for more photos of S5M-E3 9AT

Part Number S5M-E3 9AT
Manufacturer Vishay
Quantity in stock 604380 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Switching 1KV 5A 2-Pin SMC T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level S5M-E3 9AT
Datasheet download S5M-E3 9AT.pdf
Request Quotation for S5M-E3 9AT

S5M-E3 9AT Specifications

Part Number S5M-E3 9AT
Configuration Single
Product Dimensions 7.11 x 6.22 mm
Pin Count 2
Rad Hard No
Operating Temperature -55 to 150 °C
Peak Reverse Current 10 uA
Max Processing Temp 260
Peak Forward Voltage 1.15 V
Lead Finish Matte Tin
Mounting Surface Mount
Peak Reverse Repetitive Voltage 1000 V
Supplier Package SMC
Peak Average Forward Current 5 A
Peak Reverse Recovery Time 2500 ns
MSL Level 1
Peak Non-Repetitive Surge Current 100 A
Type Switching Diode
Package 2SMC
Replacement Part Number PART-S5M-E3 9AT
Weight Contact us
Country of Origin -
