Please contact us for more photos of SB540-E3 54
| Part Number | SB540-E3 54 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 698490 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 40V 5A 2-Pin DO-201AD T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | SB540-E3 54 |
| Datasheet download |  SB540-E3 54.pdf |
| Part Number | SB540-E3 54 |
|---|---|
| Lead Finish | Matte Tin |
| Product Dimensions | 10 x 5.8 x 5.8 mm |
| Supplier Package | DO-201AD |
| Mounting | Through Hole |
| Peak Reverse Current | 500 uA |
| Peak Average Forward Current | 5 A |
| Peak Forward Voltage | 0.48 V |
| Peak Reverse Repetitive Voltage | 40 V |
| Configuration | Single |
| Pin Count | 2 |
| Rad Hard | No |
| Type | Schottky Diode |
| Max Processing Temp | 260 |
| Operating Temperature | -65 to 150 °C |
| Peak Non-Repetitive Surge Current | 220 A |
| Package | 2DO-201AD |
| Replacement Part Number | PART-SB540-E3 54 |
| Weight | Contact us |
| Country of Origin | - |
