Please contact us for more photos of SD101CW-E3-08
| Part Number | SD101CW-E3-08 |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 399810 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 40V 0.03A 2-Pin SOD-123 T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | SD101CW-E3-08 |
| Datasheet download |  SD101CW-E3-08.pdf |
| Part Number | SD101CW-E3-08 |
|---|---|
| Configuration | Single |
| Operating Temperature | -55 to 125 °C |
| Peak Average Forward Current | 0.03 A |
| Peak Reverse Current | 0.2@30V uA |
| Peak Forward Voltage | 0.9@15mA V |
| Peak Reverse Repetitive Voltage | 40 V |
| Peak Non-Repetitive Surge Current | 2 A |
| Screening Level | Commercial |
| Type | Schottky Diode |
| Product Dimensions | 2.85(Max) x 1.7(Max) x 1.25(Max) |
| Supplier Package | SOD-123 |
| Mounting | Surface Mount |
| Rad Hard | No |
| Pin Count | 2 |
| Peak Reverse Recovery Time | 1 ns |
| Package | 2SOD-123 |
| Replacement Part Number | PART-SD101CW-E3-08 |
| Weight | Contact us |
| Country of Origin | - |
