Please contact us for more photos of STPS1L40A
| Part Number | STPS1L40A |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 368730 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 40V 1A 2-Pin SMA T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | STPS1L40A |
| Datasheet download |  STPS1L40A.pdf |
| Part Number | STPS1L40A |
|---|---|
| Supplier Package | SMA |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Peak Average Forward Current | 1 A |
| Peak Non-Repetitive Surge Current | 60 A |
| MSL Level | 1 |
| Product Dimensions | 4.6 x 2.95 x 2.7 mm |
| Operating Temperature | -65 to 150 °C |
| Peak Reverse Current | 35 uA |
| Peak Reverse Repetitive Voltage | 40 V |
| Peak Forward Voltage | 0.5 V |
| Pin Count | 2 |
| Rad Hard | No |
| Configuration | Single |
| Max Processing Temp | 260 |
| Type | Schottky Diode |
| Package | 2SMA |
| Replacement Part Number | PART-STPS1L40A |
| Weight | Contact us |
| Country of Origin | - |
