STTH812D STMicroelectronics

STTH812D Images

Please contact us for more photos of STTH812D

Part Number STTH812D
Manufacturer STMicroelectronics
Quantity in stock 245160 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Switching 1.2KV 8A 2-Pin(2+Tab) TO-220AC Tube
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level STTH812D
Datasheet download STTH812D.pdf
Request Quotation for STTH812D

STTH812D Specifications

Part Number STTH812D
Peak Reverse Repetitive Voltage 1200 V
Type Switching Diode
Lead Finish Tin
Peak Forward Voltage 2.2 V
Supplier Package TO-220AC
Mounting Through Hole
Peak Reverse Current 8 uA
Product Dimensions 10.4 x 4.6 x 9.3 mm
Configuration Single
Peak Average Forward Current 8 A
Operating Temperature -65 to 175 °C
Pin Count 2
Peak Reverse Recovery Time 100 ns
Peak Non-Repetitive Surge Current 80 A
Package 2TO-220AC
Replacement Part Number PART-STTH812D
Weight Contact us
Country of Origin -
