Please contact us for more photos of UMR12NTN
| Part Number | UMR12NTN |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 688400 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Switching 80V 0.1A 6-Pin UMD T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | UMR12NTN |
| Datasheet download |  UMR12NTN.pdf |
| Part Number | UMR12NTN |
|---|---|
| Peak Reverse Current | 0.1 uA |
| Mounting | Surface Mount |
| Peak Non-Repetitive Surge Current | 4 A |
| Configuration | Double Dual Series |
| Product Dimensions | 2 x 1.25 x 0.9 mm |
| Pin Count | 6 |
| Max Processing Temp | 260|265 |
| Type | Switching Diode |
| Supplier Package | UMD |
| Peak Reverse Repetitive Voltage | 80 V |
| Peak Average Forward Current | 0.1 A |
| Rad Hard | No |
| Lead Finish | Tin/Copper |
| Operating Temperature | -55 to 150 °C |
| Peak Forward Voltage | 1.2 V |
| Package | 6UMD |
| Replacement Part Number | PART-UMR12NTN |
| Weight | Contact us |
| Country of Origin | - |
