Please contact us for more photos of V40100C-E3 4W
| Part Number | V40100C-E3 4W |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 172080 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 100V 40A 3-Pin(3+Tab) TO-220AB Tube |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | V40100C-E3 4W |
| Datasheet download |  V40100C-E3 4W.pdf |
| Part Number | V40100C-E3 4W |
|---|---|
| Lead Finish | Matte Tin |
| Peak Forward Voltage | 0.73@20A V |
| Peak Reverse Repetitive Voltage | 100 V |
| Operating Temperature | -40 to 150 °C |
| Mounting | Through Hole |
| Peak Average Forward Current | 40 A |
| Configuration | Dual Common Cathode |
| Pin Count | 3 |
| Product Dimensions | 10.54 x 4.7 x 8.89 mm |
| Peak Reverse Current | 1000 uA |
| Peak Non-Repetitive Surge Current | 250 A |
| Rad Hard | No |
| Type | Schottky Diode |
| Max Processing Temp | 260 |
| Supplier Package | TO-220AB |
| Package | 3TO-220AB |
| Replacement Part Number | PART-V40100C-E3 4W |
| Weight | Contact us |
| Country of Origin | - |
