Please contact us for more photos of V8P6HM3 86A
| Part Number | V8P6HM3 86A |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 461770 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky Barrier Rectifier 60V 8A 3-Pin TO-277A Plastic T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | V8P6HM3 86A |
| Datasheet download |  V8P6HM3 86A.pdf |
| Part Number | V8P6HM3 86A |
|---|---|
| Pin Count | 3 |
| Peak Reverse Current | 600 uA |
| Rad Hard | No |
| Peak Average Forward Current | 8 A |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 150 °C |
| Type | Schottky Barrier Rectifier |
| Lead Finish | Matte Tin |
| MSL Level | 1 |
| Screening Level | Automotive |
| Configuration | Single Dual Anode |
| Peak Forward Voltage | 0.61 V |
| Product Dimensions | 4.75(Max) x 6.15(Max) x 1.2(Max) |
| Peak Non-Repetitive Surge Current | 140 A |
| Supplier Package | TO-277A |
| Peak Reverse Repetitive Voltage | 60 V |
| Package | 3TO-277A |
| Replacement Part Number | PART-V8P6HM3 86A |
| Weight | Contact us |
| Country of Origin | - |
