VS-16CTQ060STRLPBF Vishay

VS-16CTQ060STRLPBF Images

Please contact us for more photos of VS-16CTQ060STRLPBF

Part Number VS-16CTQ060STRLPBF
Manufacturer Vishay
Quantity in stock 808460 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Diode Schottky 60V 16A 3-Pin(2+Tab) D2PAK T R
Category Discrete Semiconductor
Family Diode
ROHS Compliant Yes
MSL Level VS-16CTQ060STRLPBF
Datasheet download VS-16CTQ060STRLPBF.pdf
Request Quotation for VS-16CTQ060STRLPBF

VS-16CTQ060STRLPBF Specifications

Part Number VS-16CTQ060STRLPBF
Peak Reverse Current 550 uA
Mounting Surface Mount
Product Dimensions 10.67 x 9.65 x 4.83 mm
Peak Non-Repetitive Surge Current 850 A
Peak Reverse Repetitive Voltage 60 V
Peak Average Forward Current 16 A
Peak Forward Voltage 0.88 V
Pin Count 3
Configuration Dual Common Cathode
Operating Temperature -55 to 175 °C
Rad Hard No
Supplier Package D2PAK
Type Schottky Diode
Package 3D2PAK
Replacement Part Number PART-VS-16CTQ060STRLPBF
Weight Contact us
Country of Origin -
