Please contact us for more photos of VS-6CWQ10FNPbF
| Part Number | VS-6CWQ10FNPbF |
|---|---|
| Manufacturer | Vishay |
| Quantity in stock | 751620 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Schottky 100V 7A 3-Pin(2+Tab) DPAK Tube |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | VS-6CWQ10FNPbF |
| Datasheet download |  VS-6CWQ10FNPbF.pdf |
| Part Number | VS-6CWQ10FNPbF |
|---|---|
| Mounting | Surface Mount |
| Peak Non-Repetitive Surge Current | 440 A |
| Product Dimensions | 6.73 x 6.22 x 2.39 mm |
| Peak Forward Voltage | 0.96@6A V |
| Peak Reverse Repetitive Voltage | 100 V |
| Configuration | Dual Common Cathode |
| Operating Temperature | -40 to 150 °C |
| MSL Level | 1 |
| Pin Count | 3 |
| Peak Average Forward Current | 7 A |
| Lead Finish | Tin |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Supplier Package | DPAK |
| Type | Schottky Diode |
| Peak Reverse Current | 1000 uA |
| Package | 3DPAK |
| Replacement Part Number | PART-VS-6CWQ10FNPbF |
| Weight | Contact us |
| Country of Origin | - |
