VS-STPS1045BTR-M3 Vishay

VS-STPS1045BTR-M3 Images

Please contact us for more photos of VS-STPS1045BTR-M3

Part Number	VS-STPS1045BTR-M3
Manufacturer	Vishay
Quantity in stock	470110 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Diode Schottky 45V 10A 3-Pin(2+Tab) DPAK T R
Category	Discrete Semiconductor
Family	Diode
ROHS Compliant	Yes
MSL Level	VS-STPS1045BTR-M3
Datasheet download	VS-STPS1045BTR-M3.pdf

Request Quotation for VS-STPS1045BTR-M3

VS-STPS1045BTR-M3 Specifications

Part Number	VS-STPS1045BTR-M3
Configuration	Single Dual Anode
Operating Temperature	-40 to 175 °C
Product Dimensions	6.73 x 6.22 x 2.39 mm
Peak Reverse Current	200 uA
Supplier Package	DPAK
Peak Reverse Repetitive Voltage	45 V
Peak Forward Voltage	0.84@20A V
Type	Schottky Diode
Peak Average Forward Current	10 A
Rad Hard	No
Pin Count	3
Mounting	Surface Mount
Peak Non-Repetitive Surge Current	390 A
Package	3DPAK
Replacement Part Number	PART-VS-STPS1045BTR-M3
Weight	Contact us
Country of Origin	-
