Please contact us for more photos of R5F523T3ADFL#30
| Part Number | R5F523T3ADFL#30 |
|---|---|
| Manufacturer | Renesas Electronics |
| Quantity in stock | 453580 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-Bit RX23T RX CISC 64KB Flash 3.3V 5V 48-Pin LFQFP Tray |
| Category | Microcontrollers MCU IC |
| Family | 32 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | R5F523T3ADFL#30 |
| Datasheet download |  R5F523T3ADFL#30.pdf |
| Part Number | R5F523T3ADFL#30 |
|---|---|
| Instruction Set Architecture | CISC |
| Supplier Package | LFQFP |
| Operating Temperature | -40 to 85 °C |
| Rad Hard | No |
| Program Memory Size | 64 KB |
| Mounting | Surface Mount |
| MSL Level | 3 |
| Max Processing Temp | 260 |
| Maximum Operating Supply Voltage | 5.5 V |
| Maximum Speed | 40 MHz |
| Operating Supply Voltage | 3.3|5 V |
| RAM Size | 10 KB |
| Product Dimensions | 7 x 7 x 1.4 |
| Number of Timers | 14 |
| On-Chip ADC | 10-chx12-bit |
| Interface Type | CSI/I2C/SPI/UART |
| Minimum Operating Supply Voltage | 2.7 V |
| Lead Finish | Pure Tin |
| Number of Programmable I/Os | 35 |
| Screening Level | Industrial |
| Pin Count | 48 |
| Package | 48LFQFP |
| Replacement Part Number | PART-R5F523T3ADFL#30 |
| Weight | Contact us |
| Country of Origin | - |
