Please contact us for more photos of R5F562T7DDFK#V3
| Part Number | R5F562T7DDFK#V3 |
|---|---|
| Manufacturer | Renesas Electronics |
| Quantity in stock | 312360 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-Bit RX62T RX CISC 128KB Flash 5V 64-Pin LQFP Tray |
| Category | Microcontrollers MCU IC |
| Family | 32 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | R5F562T7DDFK#V3 |
| Datasheet download |  R5F562T7DDFK#V3.pdf |
| Part Number | R5F562T7DDFK#V3 |
|---|---|
| Lead Finish | Pure Tin |
| Program Memory Type | Flash |
| Maximum Expanded Memory Size | 4 GB |
| RAM Size | 8 KB |
| Instruction Set Architecture | CISC |
| Number of Programmable I/Os | 46 |
| Supplier Package | LQFP |
| Product Dimensions | 14 x 14 x 1.4 |
| Watchdog | 2 |
| Number of Timers | 16 |
| Data Memory Size | 8 KB |
| On-Chip ADC | 8-chx12-bit |
| Device Core | RX |
| Maximum Speed | 100 MHz |
| Operating Supply Voltage | 5 V |
| Interface Type | CSI/I2C/LIN/SPI/UART |
| Minimum Operating Supply Voltage | 4 V |
| Screening Level | Industrial |
| Rad Hard | No |
| Program Memory Size | 128 KB |
| Mounting | Surface Mount |
| Data Bus Width | 32 Bit |
| MSL Level | 3 |
| Max Processing Temp | 260 |
| Operating Temperature | -40 to 85 °C |
| Pin Count | 64 |
| Maximum Operating Supply Voltage | 5.5 V |
| Package | 64LQFP |
| Replacement Part Number | PART-R5F562T7DDFK#V3 |
| Weight | Contact us |
| Country of Origin | - |
