Please contact us for more photos of R5F563NFDDFP#V0
| Part Number | R5F563NFDDFP#V0 |
|---|---|
| Manufacturer | Renesas Electronics |
| Quantity in stock | 613320 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | MCU 32-Bit RX63N RX CISC 2048KB Flash 3.3V 100-Pin LFQFP Tray |
| Category | Microcontrollers MCU IC |
| Family | 32 Bit Microcontrollers MCU |
| ROHS Compliant | Yes |
| MSL Level | R5F563NFDDFP#V0 |
| Datasheet download |  R5F563NFDDFP#V0.pdf |
| Part Number | R5F563NFDDFP#V0 |
|---|---|
| Instruction Set Architecture | CISC |
| On-Chip DAC | 1-chx10-bit |
| Data Memory Size | 32 KB |
| Maximum Speed | 100 MHz |
| Pin Count | 100 |
| Product Dimensions | 14 x 14 x 1.4 |
| Rad Hard | No |
| Supplier Package | LFQFP |
| Watchdog | 2 |
| Operating Temperature | -40 to 85 °C |
| Number of Timers | 20 |
| Special Features | CAN Controller |
| Device Core | RX |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Number of Programmable I/Os | 79 |
| MSL Level | 3 |
| RAM Size | 256 KB |
| Operating Supply Voltage | 3.3 V |
| Data Bus Width | 32 Bit |
| Lead Finish | Pure Tin |
| Screening Level | Industrial |
| On-Chip ADC | 8-chx10-bit|14-chx12-bit |
| Interface Type | CAN/CSI/Ethernet/I2C/IEBus/SPI/UART/USB |
| Program Memory Type | Flash |
| Program Memory Size | 2048 KB |
| Minimum Operating Supply Voltage | 2.7 V |
| Maximum Operating Supply Voltage | 3.6 V |
| Maximum Expanded Memory Size | 4 GB |
| Package | 100LFQFP |
| Replacement Part Number | PART-R5F563NFDDFP#V0 |
| Weight | Contact us |
| Country of Origin | - |
