Please contact us for more photos of ABA-54563-TR1G
| Part Number | ABA-54563-TR1G |
|---|---|
| Manufacturer | Broadcom |
| Quantity in stock | 553540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | RF Amp Chip Single GP 3.4GHz 6-Pin SOT-363 T R |
| Category | RF & Microwave |
| Family | Amplifiers |
| ROHS Compliant | Yes |
| MSL Level | ABA-54563-TR1G |
| Datasheet download |  ABA-54563-TR1G.pdf |
| Part Number | ABA-54563-TR1G |
|---|---|
| Manufacturer Type | Broadband Amplifier |
| Maximum Operating Frequency Range | 3000 to 5000 MHz |
| Maximum Supply Current | 90@5V mA |
| Typical Power Gain | 23@2000MHz dB |
| Typical Output Power | 16.1@2000MHz dBm |
| Maximum Input VSWR :1 | 1.11 |
| Typical Noise Figure | 4.4@2000MHz dB |
| Typical Output Intercept Point | 27.8@2000MHz dBm |
| Rad Hard | No |
| Typical Single Supply Voltage | 5 V |
| Pin Count | 6 |
| Supplier Package | SOT-363 |
| Typical Gain Flatness | 3 dB |
| Max Processing Temp | 260 |
| Product Dimensions | 2.25 x 1.35 x 1 mm |
| Maximum Power Dissipation | 560 mW |
| Operating Temperature | N/A to 150 °C |
| Type | General Purpose Amplifier |
| Lead Finish | Matte Tin |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Power Supply Type | Single |
| Number of Channels per Chip | 1 |
| Package | 6SOT-363 |
| Replacement Part Number | PART-ABA-54563-TR1G |
| Weight | Contact us |
| Country of Origin | - |
