Please contact us for more photos of NLB-310-T1
| Part Number | NLB-310-T1 |
|---|---|
| Manufacturer | QORVO |
| Quantity in stock | 627790 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | CASCADABLE BROADBAND GAAS MMIC AMPLIFIER |
| Category | RF & Microwave |
| Family | Amplifiers |
| ROHS Compliant | Yes |
| MSL Level | NLB-310-T1 |
| Datasheet download |  NLB-310-T1.pdf |
| Part Number | NLB-310-T1 |
|---|---|
| Maximum Input VSWR :1 | 1.75 |
| Type | MMIC Amplifier |
| Typical Output Power | 12.6@10000MHz dBm |
| Rad Hard | No |
| Minimum Single Supply Voltage | 4.4 V |
| Maximum Single Supply Voltage | 4.8 V |
| Maximum Operating Frequency | 10000 MHz |
| Power Supply Type | Single |
| Maximum Power Dissipation | 300 mW |
| Manufacturer Type | MMIC Amplifier |
| Typical Gain Flatness | ±0.3 dB |
| Packaging | Tape and Reel |
| Maximum Supply Current | [email protected] mA |
| Maximum Operating Frequency Range | 0 to 10000 MHz |
| Maximum Reverse Isolation | -17 dB |
| Maximum Output VSWR :1 | 1.8 |
| Mounting | Surface Mount |
| Typical Single Supply Voltage | 4.6 V |
| Number of Channels per Chip | 1 |
| Operating Temperature | -45 to 85 °C |
| Typical Output Intercept Point | 28.9@10000MHz dBm |
| Lead Free | Yes |
| Typical Power Gain | 12.7@10000MHz dB |
| Family | NLB-310 |
| Screening Level | Industrial |
| Typical Noise Figure | 5@10000MHz dB |
| Package | 4Micro-X |
| Replacement Part Number | PART-NLB-310-T1 |
| Weight | Contact us |
| Country of Origin | - |
