Please contact us for more photos of RFPA5532TR13
| Part Number | RFPA5532TR13 |
|---|---|
| Manufacturer | QORVO |
| Quantity in stock | 161750 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | RF Amp Chip Single Power Amplifier 5925MHz 3.6V 20-Pin QFN T R |
| Category | RF & Microwave |
| Family | Amplifiers |
| ROHS Compliant | Yes |
| MSL Level | RFPA5532TR13 |
| Datasheet download |  RFPA5532TR13.pdf |
| Part Number | RFPA5532TR13 |
|---|---|
| Maximum Supply Current | [email protected] mA |
| Rad Hard | No |
| Maximum Single Supply Voltage | 3.6 V |
| Operating Temperature | -40 to 85 °C |
| Power Supply Type | Single |
| Minimum Single Supply Voltage | 3 V |
| Maximum Input Return Loss | 12@5925MHz dB |
| Type | Power Amplifier |
| Typical Single Supply Voltage | 3.3 V |
| Mounting | Surface Mount |
| Maximum Processing Temperature | 260 °C |
| Pin Count | 20 |
| Package Dimensions | 4 x 4 x 0.85 mm |
| Number of Channels per Chip | 1 |
| Moisture Sensitivity Level | 2 |
| Maximum Output VSWR :1 | 6 |
| Typical Power Gain | 32@5925MHz dB |
| Typical Output Power | 30@5925MHz dBm |
| Screening Level | Industrial |
| Maximum Operating Frequency | 5925 MHz |
| Maximum Output Return Loss | 8@5925MHz dB |
| Maximum Operating Frequency Range | 4900 to 5925 MHz |
| Manufacturer Type | Power Amplifier |
| Supplier Package | QFN |
| Package | 20QFN |
| Replacement Part Number | PART-RFPA5532TR13 |
| Weight | Contact us |
| Country of Origin | - |
