Please contact us for more photos of MCR100JZHJ5R1
| Part Number | MCR100JZHJ5R1 |
|---|---|
| Manufacturer | ROHM |
| Quantity in stock | 156490 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Thick Film 2512 5.1 Ohm 5% 1W \u00b1500ppm \u00b0C Molded SMD Embossed T R |
| Category | Resistor |
| Family | Resistor Fixed Single-Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | MCR100JZHJ5R1 |
| Datasheet download |  MCR100JZHJ5R1.pdf |
| Part Number | MCR100JZHJ5R1 |
|---|---|
| Mounting | Surface Mount |
| Power Rating | 1 W |
| Product Dimensions | 6.3 x 3.2 x 0.55 |
| Operating Temperature | -55 to 125 °C |
| Lead Finish | Tin Over Nickel |
| Package Type | SMD |
| Temperature Coefficient | ±500 ppm/°C |
| Failure Rate | |
| Military Standard | |
| Resistance Value | 5.1 Ohm |
| Case Size | 2512 |
| Max Processing Temp | 260 |
| Tolerance | 5 % |
| Case Style | Molded |
| Type | Thick Film |
| Rad Hard | No |
| Pin Count | 2 |
| Supplier Package | 2512 |
| Termination Style | Wraparound |
| Product Depth | 3.2 mm |
| Product Height | 0.55 mm |
| Product Length | 6.3 mm |
| Replacement Part Number | PART-MCR100JZHJ5R1 |
| Weight | Contact us |
| Country of Origin | - |
