Please contact us for more photos of HTSW-102-42-F-D
| Part Number | HTSW-102-42-F-D |
|---|---|
| Manufacturer | Samtec |
| Quantity in stock | 531260 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST Thru-Hole |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | HTSW-102-42-F-D |
| Datasheet download |  HTSW-102-42-F-D.pdf |
| Part Number | HTSW-102-42-F-D |
|---|---|
| Rad Hard | No |
| Max Processing Temp | 260 |
| Pitch | 2.54 mm |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold Over Nickel |
| Product Dimensions | 5.08 x 5.02 x 10.67 mm |
| Housing Material | Liquid Crystal Polymer |
| Housing Color | Natural |
| Lead Finish | Matte Tin |
| Termination Method | Solder |
| Gender | HDR |
| Mounting | Through Hole |
| Operating Temperature | -55 to 125 °C |
| Body Orientation | Straight |
| Product Depth | 5.02 mm |
| Product Height | 10.67 mm |
| Product Length | 5.08 mm |
| Replacement Part Number | PART-HTSW-102-42-F-D |
| Weight | Contact us |
| Country of Origin | - |
