Please contact us for more photos of TFM-115-01-S-D
| Part Number | TFM-115-01-S-D |
|---|---|
| Manufacturer | Samtec |
| Quantity in stock | 150760 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Shrouded Header HDR 30 POS 1.27mm Solder ST Thru-Hole Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | TFM-115-01-S-D |
| Datasheet download |  TFM-115-01-S-D.pdf |
| Part Number | TFM-115-01-S-D |
|---|---|
| Lead Finish | Matte Tin |
| Operating Temperature | -55 to 125 °C |
| Rad Hard | No |
| Housing Color | Black |
| Termination Method | Solder |
| Gender | HDR |
| Body Orientation | Straight |
| Housing Material | Liquid Crystal Polymer |
| Pitch | 1.27 mm |
| Contact Plating | Gold Over Nickel |
| Mounting | Through Hole |
| Product Dimensions | 22.23 x 5.72 x 5.59 mm |
| Contact Material | Phosphor Bronze |
| Max Processing Temp | 260 |
| Product Depth | 5.72 mm |
| Product Height | 5.59 mm |
| Product Length | 22.23 mm |
| Replacement Part Number | PART-TFM-115-01-S-D |
| Weight | Contact us |
| Country of Origin | - |
