| Part Number | TSM-104-01-L-DH-A |
|---|---|
| Manufacturer | Samtec |
| Quantity in stock | 862500 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Unshrouded Header HDR 8 POS 2.54mm Solder RA SMD |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | TSM-104-01-L-DH-A |
| Datasheet download |  TSM-104-01-L-DH-A.pdf |
| Part Number | TSM-104-01-L-DH-A |
|---|---|
| Housing Material | Liquid Crystal Polymer |
| Product Dimensions | 10.16 x 15.09 x 6.1 mm |
| Max Processing Temp | 260 |
| Contact Material | Phosphor Bronze |
| Contact Plating | Gold Over Nickel |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Body Orientation | Right Angle |
| Operating Temperature | -55 to 125 °C |
| MSL Level | 1 |
| Gender | HDR |
| Mounting | Surface Mount |
| Termination Method | Solder |
| Housing Color | Black |
| Pitch | 2.54 mm |
| Product Depth | 15.09 mm |
| Product Height | 6.1 mm |
| Product Length | 10.16 mm |
| Replacement Part Number | PART-TSM-104-01-L-DH-A |
| Weight | Contact us |
| Country of Origin | - |
