Please contact us for more photos of NCP4305DMNTWG
| Part Number | NCP4305DMNTWG |
|---|---|
| Manufacturer | ON Semiconductor |
| Quantity in stock | 238270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Secondary Side PWM Cntrlr Secondary Side Synchronous Rectifier Driver 1000KHz 8-Pin DFN T R |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | NCP4305DMNTWG |
| Datasheet download |  NCP4305DMNTWG.pdf |
| Part Number | NCP4305DMNTWG |
|---|---|
| Switching Frequency | 1000 kHz |
| Lead Finish | Matte Tin |
| Mounting | Surface Mount |
| Supplier Package | DFN |
| Pin Count | 8 |
| MSL Level | 1 |
| Operating Supply Voltage | -0.3 to 37 V |
| Product Dimensions | 4 x 4 x 0.95 |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Screening Level | Extended Industrial |
| Operating Temperature | -40 to 125 °C |
| Package | 8DFN |
| Replacement Part Number | PART-NCP4305DMNTWG |
| Weight | Contact us |
| Country of Origin | - |
