Please contact us for more photos of 1825264-2
| Part Number | 1825264-2 |
|---|---|
| Manufacturer | TE Connectivity |
| Quantity in stock | 511110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Slide 4PDT Extended Top Slide 20VAC 20VDC 0.4VA PC Pins Thru-Hole Tray |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | 1825264-2 |
| Datasheet download |  1825264-2.pdf |
| Part Number | 1825264-2 |
|---|---|
| Maximum Current Rating | 0.3@125VAC |
| Contact Material | Copper Alloy |
| Actuator Material | Polyester |
| Product Dimensions | 15 x 9.4 x 18 mm |
| Maximum Power Rating | 0.4@20VAC 20VDC |
| Mounting | Through Hole |
| Terminal Type | PC Pins |
| Maximum DC Voltage Rating | 20 |
| Actuator Style | Extended Top Slide |
| Pole Throw Configuration | 4PDT |
| Rad Hard | No |
| Contact Plating | Gold |
| Max Processing Temp | 240|260|265 |
| Operating Temperature | -20 to 85 °C |
| Lead Finish | Gold |
| Replacement Part Number | PART-1825264-2 |
| Weight | Contact us |
| Country of Origin | - |
