Please contact us for more photos of 7A13-A1PCAE2
| Part Number | 7A13-A1PCAE2 |
|---|---|
| Manufacturer | Eledis |
| Quantity in stock | 165650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Slide ON Off ON SPDT Top Slide 20VDC PC Pins Thru-Hole Tray |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | 7A13-A1PCAE2 |
| Datasheet download |  7A13-A1PCAE2.pdf |
| Part Number | 7A13-A1PCAE2 |
|---|---|
| Maximum Current Rating | 1@20VAC VDC A |
| Mechanical Life | 30000 Cycles |
| Contact Plating | Gold |
| Operating Temperature | -30 to 85 °C |
| Switch Configuration | ON Off ON |
| Mounting | Through Hole |
| Actuator Style | Top Slide |
| Pin Count | 3 |
| Pole Throw Configuration | SPDT |
| Maximum Power Rating | 0.4 VA |
| Base/Housing Material | Stainless Steel |
| Contact Material | Copper Alloy |
| Terminal Type | PC Pins |
| Type | Miniature |
| Rad Hard | No |
| Maximum DC Voltage Rating | 20 V |
| Maximum AC Voltage Rating | 20 V |
| Lead Finish | Gold |
| Actuator Material | Nylon |
| Product Dimensions | 19.56 x 6.6 x 11.43 |
| Replacement Part Number | PART-7A13-A1PCAE2 |
| Weight | Contact us |
| Country of Origin | - |
