Please contact us for more photos of V802-13-SS-05-Q
| Part Number | V802-13-SS-05-Q |
|---|---|
| Manufacturer | C&K |
| Quantity in stock | 111930 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Switch Slide DPDT Screwdriver 10.1A 250VAC 28VDC Quick Connect Panel Mount |
| Category | Switches and Relays |
| Family | Switches |
| ROHS Compliant | Yes |
| MSL Level | V802-13-SS-05-Q |
| Datasheet download |  V802-13-SS-05-Q.pdf |
| Part Number | V802-13-SS-05-Q |
|---|---|
| Base/Housing Material | N/A/Nylon 6/6 |
| Operating Temperature | -30 to 85 °C |
| Mounting | Panel Mount |
| Actuator Material | Glass/Polyester |
| Pole Throw Configuration | DPDT |
| Actuator Style | |
| Type | Power and Line Voltage Select |
| Terminal Type | |
| Maximum Power Rating | |
| Mechanical Life | |
| Maximum AC Voltage Rating | 250 V |
| Rad Hard | No |
| Product Dimensions | 41 x 16.5 x 22.75 mm |
| Contact Material | Copper |
| Lead Finish | Silver |
| Maximum Current Rating | 10.1@125VAC@(CSA/UL) A |
| Contact Plating | Silver |
| Replacement Part Number | PART-V802-13-SS-05-Q |
| Weight | Contact us |
| Country of Origin | - |
