Please contact us for more photos of 1.5KE100A
| Part Number | 1.5KE100A |
|---|---|
| Manufacturer | STMicroelectronics |
| Quantity in stock | 209960 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Uni-Dir 85.5V 1.5KW 2-Pin DO-201 T R |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | 1.5KE100A |
| Datasheet download |  1.5KE100A.pdf |
| Part Number | 1.5KE100A |
|---|---|
| Maximum Peak Pulse Current | 56 A |
| Maximum Reverse Stand-off Voltage | 85.5 V |
| Maximum Reverse Leakage Current | 1 uA |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| ESD Protection | No |
| Product Dimensions | 9.5 x 5.3 x 5.3 mm |
| Minimum Breakdown Voltage | 95 V |
| Direction Type | Uni-Directional |
| Operating Temperature | -65 to 175 °C |
| Configuration | Single |
| Peak Pulse Power Dissipation | 1500 W |
| Mounting | Through Hole |
| Max Processing Temp | 230 |
| Pin Count | 2 |
| Maximum Clamping Voltage | 178 V |
| Test Current | 1 mA |
| Supplier Package | DO-201 |
| Package | 2DO-201 |
| Replacement Part Number | PART-1.5KE100A |
| Weight | Contact us |
| Country of Origin | - |
